Модель: MPP series
марка: Рата
| Продажа единиц жилья: | pcs |
The file is encrypted. Please fill in the following information to continue accessing it
|
MODEL |
EV160-S Pro |
EV170-S Prp |
EV185-2 |
EV200-2 |
EV225-X |
EV340 |
EV450 |
EV550 |
E2V670E |
E2V740E |
|
Engine type |
Single cylinder, 4-Stroke(OHV) |
V-Twin cylinder,4-stroke(OHV) |
||||||||
|
Bore×Stroke （mm） |
68 x 44.2mm |
70x 44.2mm |
70x 48mm |
73 x 48mm |
72x 55mm |
88x56mm |
92x67.6mm |
94.5 x 78mm |
78 x 70mm |
82 x 70mm |
|
Displacement（cc） |
160.5cc |
170cc |
185cc |
201cc |
224cc |
340cc |
449cc |
547cc |
670cc |
739cc |
|
Compression ratio |
8.2:1 |
9.0:1 |
8.5:1 |
8.7 :1 |
8.3 :1 |
8.2:1 |
8.9 :1 |
8.6 :1 |
7.8 :1 |
7.8:1 |
|
Net power |
2.8kw/3600rpm |
3.0kw/3600rpm |
3.8kw/3600rpm |
4kw/3600rpm |
4.0kw /3600rpm |
6.7kw /3600rpm |
10kw /3600rpm |
12kw /3600rpm |
15.5kw/3600rpm |
17.5kw /3600rpm |
|
Net torque |
8.5Nm/2500rpm |
9.0N.m /2500rpm |
11.5N.m /2500rpm |
11.8N.m /2500rpm |
12.5N.m/2500rpm |
17.8N.m/2500rpm |
30Nm/2500rpm |
36.2N.m /3000rpm |
45N.m / 2500rpm |
51N.m /2500rpm |
|
PTO shaft rotation |
Counterclockwise (Vertical shaft output) |
Counterclockwise(Verticalshaft output) |
||||||||
|
lgnition system |
Electromagnetic ignition |
Electromagnetic ignition |
||||||||
|
Starting system |
Recoil / Electric starter |
Electric starter |
||||||||
|
Lubrication system |
Splash |
Splash+Pressure |
||||||||
|
Carburetor |
Float carburetor |
Float carburetor |
||||||||
|
Governor system |
Centrifugal mechanical |
Centrifugal mechanical |
||||||||
|
Air cleaner |
Foam + Cylinder paper |
Foam + Cylinder paper |
||||||||
|
Oil capacity |
0.5L |
0.5L |
0.5L |
0.5L |
0.6L |
1.1L |
1.5L |
1.6L |
2.0L |
2.0L |
|
Fuel tank capacity |
0.8L |
0.8L |
1.5L |
1.5L |
1.0L |
3.5L |
/ |
/ |
/ |
/ |
|
Dimensions(LxWxH) |
365 x 330 x 240mm |
360 x 330 x 240mm |
405 x 360 x 290mm |
405 x360 x 290mm |
432x422x297mm |
540x460x320mm （w muffler,w/o tank,w/o recoil） |
460 x 415x306mm |
480 x 470x 315mm |
475 x 448 x 365mm |
475x448x 365mm |
|
Net weight |
8.8kg |
9.0kg |
11kg |
11kg |
15.5 |
8.8kg |
29.3kg |
35kg |
39kg |
38.5kg |
